Industrial Rolled Products
ronden

Sheet, Plate and Circles

Aurubis’ sheet and plate have an unrivaled range of dimensions that are unique in the marketplace and manufactured for various applications and critical parts of many diverse products.

The sheet and plate are further processed into MRI scanners, heavy gauge printed circuit boards (PCBs), printing plates for engraving, sputtering targets and semi-conductors. Aurubis circles are further processed into cymbals, for instance.

Applications:
  • Wind energy, domestic heating, general industrial engineering, bus bars, stamping and pressing applications
Alloys
Pure copper alloys and low-alloyed copper
ISO UNS EN JIS Buffalo Pori Stolberg
Cu-OFE (OF-Cu) C10200 CW009A C1011 C101 Cu-OFE PNA 203
Cu-OF C10200 CW008A C1020 C102 Cu-OF
Cu-HCP (SE-Cu 57) C10300 CW021A   C103 Cu-HCP PNA 210
Cu-XLP / Cu-PHC (SE-Cu 58) C10300 CW020A   C103 Cu-XLP PNA 209
CuAg0.03(OF) (CuAg0.03P) C11300         PNA 202
CuAg0.04 (OF) C10400 CW017A     CuAg0.04 (OF)
CuAg0.045 (OF)         CuAg0.05 (OF)
CuAg0.10P C10700 CW016A     CuAg0.10P PNA 217
CuAg0.10 C10700 CW013A     CuAg0.10
CuAg0.10 (OF) C10700 CW019A     CuAg0.10 (OF)
Cu-ETP (E-Cu) C11000 CW004A C1100 C110 Cu-ETP PNA 211
Cu-DLP C12000 CW023A C1201 C120 Cu-DLP PNA 220
Cu-DHP (SF-Cu) C12200 CW024A C1221 C122 Cu-DHP PNA 219
Brass
ISO UNS EN JIS Buffalo Pori Stolberg
CuZn42 BlueBrass®           PNA 378
Sheet sizes (ratio of width to thickness on request)
